GarageBand Vocal Chain Settings for Rap, R&B and Pop

By TuneDrip Team Updated 4 min read
GarageBand Vocal Chain Settings: TuneDrip cover with a chain of five audio processor modules with lit knobs on a dark background

GarageBand on the Mac has everything you need for a clean, modern vocal: Channel EQ, Compressor, DeEsser 2, a pitch correction control and reverb and echo sends. What most tutorials leave out are the numbers. This guide gives you exact starting settings for rap, R&B and pop, the order to put the plugins in, and how to load ready-made GarageBand vocal presets if you would rather start from a finished chain.

GarageBand vocal chain order

In GarageBand, plugins on a track run from top to bottom in the Plug-ins area of the Smart Controls inspector. Use this order:

  1. Pitch correction (track setting, not a plugin slot: see below).
  2. Channel EQ for the high-pass and problem cuts.
  3. Compressor to even out the performance.
  4. DeEsser 2 to tame "s" and "t" sounds.
  5. Channel EQ (second instance) for presence and air, if needed.
  6. Reverb and echo through the track's sends rather than as inserts.

The logic behind this order is explained in the correct vocal chain order.

GarageBand vocal chain settings for rap

  • Channel EQ: high-pass at 100 Hz; cut 2 to 3 dB around 300 Hz if the voice sounds boxy; +2 to +3 dB around 3 kHz for presence.
  • Compressor: ratio 4:1 to 6:1, attack 3 to 5 ms, release 50 to 80 ms, threshold set for 5 to 8 dB of gain reduction on loud words; raise the gain to match the bypassed level.
  • DeEsser 2: frequency around 6 to 7 kHz, reduce until harsh "s" sounds drop without the voice sounding lispy.
  • Reverb send: low; a short space keeps rap vocals upfront.
  • Echo send: a little 1/8 echo on the ends of lines.

GarageBand vocal chain settings for R&B

  • Channel EQ: high-pass at 80 Hz to keep warmth; gentle cut around 400 Hz; +1 to +2 dB around 2.5 kHz; +1 to +2 dB shelf around 10 kHz.
  • Compressor: ratio 3:1, attack 10 to 20 ms, release Auto or around 100 ms, 3 to 5 dB of reduction.
  • DeEsser 2: around 6 kHz, moderate.
  • Reverb send: higher than for rap; a darker, longer space suits R&B.

GarageBand vocal chain settings for pop

  • Channel EQ: high-pass at 100 to 120 Hz; small cut around 250 to 350 Hz; +2 dB around 3 to 4 kHz; +2 dB shelf around 12 kHz for air.
  • Compressor: ratio 3:1 to 4:1, attack 5 to 10 ms, 4 to 6 dB of reduction for a very even level.
  • DeEsser 2: around 7 kHz; bright pop EQ makes sibilance more obvious, so check it after the air boost.
  • Reverb and echo sends: medium reverb plus a 1/4 echo on the hook.

Pitch correction in GarageBand

GarageBand's built-in pitch correction lives in the track settings, not in a plugin slot. Open the audio region editor, turn on Limit to Key so it corrects to the project key, then raise the Pitch Correction slider. Around 50 to 60 gives a natural correction; 90 to 100 gives the obvious, robotic Auto-Tune effect used in trap. Set the project key correctly first, or the correction will pull notes to the wrong pitch.

GarageBand on Mac also loads Audio Unit (AU) plugins, so you can use a dedicated tuner with more control, such as Tune Live, our real-time autotune plugin, which adds retune speed, humanize, flex-tune and automatic key detection. For settings by style, see the Auto-Tune settings guide.

GarageBand vocal presets: how to load a ready-made chain

GarageBand saves channel strip settings (.cst files) and patches. Copy the preset into GarageBand's user patch or channel strip folder, then load it from the Library on a vocal track. Our step-by-step guide shows how to install a vocal preset in GarageBand, and how to use vocal presets in GarageBand covers the full workflow from recording to mix.

TuneDrip's artist and genre preset packs include a GarageBand version built with stock plugins: browse the GarageBand vocal presets collection or start with the free vocal presets.

GarageBand on iPhone and iPad

GarageBand for iOS has track-level EQ, compressor and reverb and echo sends, but it does not load Mac channel strip presets or AU plugins in the same way. Use the settings above as a guide for its built-in controls, or record on iOS and mix on a Mac.

FAQ

What are the best vocal settings in GarageBand?

For most voices: high-pass around 80 to 120 Hz, a compressor at 3:1 to 4:1 with 4 to 6 dB of reduction, DeEsser 2 around 6 to 7 kHz, a small presence boost around 3 kHz and reverb on a send. Use the genre sections above to fine-tune.

Does GarageBand have autotune?

Yes. Turn on Limit to Key and raise the Pitch Correction slider in the track's region editor. At 90 to 100 it produces the hard Auto-Tune effect; at 50 to 60 it corrects more naturally.

Can I use vocal presets in GarageBand?

Yes, on Mac. GarageBand loads channel strip and patch presets built with its stock plugins, and AU plugin presets if you own those plugins.

Why does my GarageBand vocal sound thin?

Usually a high-pass set too high, too much cut in the low mids, or too much compression. Lower the high-pass to 80 Hz, undo cuts below 300 Hz and aim for 3 to 5 dB of gain reduction.
